Single Zone Mega and Mega 115V Wall Mounted Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Electrical
Nominal
Tons
Unit Model
No.
Hertz Voltage
Voltage
Range (Min.
to Max.)
MCA MOP
Com-
pressor
Quantity
Compressor Motor
RLA
Outdoor Fan
Motor
Indoor Fan Motor
Cooling Heating W FLA W FLA
3/4 LS090HEV2
60 208 - 230 187 - 253
10.0 15 1 7.0 7.0 43 0.4 30 0.4
1 LS120HEV2 10.0 15 1 7.0 7.0 43 0.4 30 0.4
1-1/2 LS180HEV2 15.0 20 1 10.0 10.0 85 0.4 58 0.4
2 LS240HEV2 15.0 20 1 10.0 10.0 85 0.4 58 0.4
Table 3: 208-230V, 60Hz, 1-Phase Single-Zone Mega System Electrical Data Table.
Table 4: 115V, 60Hz, 1-Phase Single Zone Single-Zone Mega 115V System Electrical Data Table.
Nominal
Tons
Unit Model
No.
Hertz Voltage
Voltage
Range (Min.
to Max.)
MCA MOP
Com-
pressor
Quantity
Compressor Motor
RLA
Outdoor Fan
Motor
Indoor Fan Motor
Cooling Heating W FLA W FLA
3/4 LS090HXV
60 115 104-127
13.5 20 1 10.0 10.0 43 0.4 30 0.5
1 LS120HXV 13.5 20 1 10.0 10.0 43 0.4 30 0.5
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOP) is calculated as follows: (Largest motor FLA x 2.25) + (Sum of
other motor FLA) rounded down to the nearest standard fuse size.
RLA = Rated Load Amps.
FLA = Full Load Amps.
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOP) is calculated as follows: (Largest motor FLA x 2.25) + (Sum of
other motor FLA) rounded down to the nearest standard fuse size.
RLA = Rated Load Amps.
FLA = Full Load Amps.
