- 7 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
No. Item Specication Remarks
4 Scart Input (1EA) PAL, SECAM
Scart jack is Full scart and support
ATV/DTV-Out
(not support MNT-Out)
5 RS-232C
SVC, Control, Power outlet
(Selectable 12V/1A or 5V/2A)
6 RGB Input (1EA) RGB-PC Analog (D-SUB 15PIN)
7 HDMI Input (3EA)
HDMI1-DTV
HDMI2-DTV
HDMI3-DTV
HDMI1 : ARC Support(HDMI Version 1.4)
Support HDCP
8 Audio Input (1EA) RGB/DVI Audio L/R Input
9 SPDIF out (1EA) SPDIF out
10 USB (2EA)
EMF, DivX HD,
For SVC (download)
JPEG, MP3, DivX HD
11 Ethernet Connect(2EA) Ethernet Connect WOL Support
12 CI Slot(1EA) CI EU PPV CH. Support
13 Clock LED Clock LED Clock Display
14
Ext. Speaker out(1EA) Ext. Speaker out Stereo 1W / 8Ω, Variable
Ext. Volume control(1EA) Ext. volume control
5. RGB input (PC)
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark
1 720*400 31.468 70.08 28.321 For only DOS mode
2 640*480 31.469 59.94 25.17 VESA
Input 848*480 60Hz, 852*480 60Hz
→ 640*480 60Hz Display
3 800*600 37.879 60.31 40.00 VESA
4 1024*768 48.363 60.00 65.00 VESA(XGA)
5 1360*768 47.72 59.8 84.75 WXGA
6 1920*1080 66.587 59.93 138.625 WUXGA FHD model
