LG LT66 Series Service Manual

- 8 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
6. HDMI Input
6.1. DTV mode
No. Resolution H-freq.(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Proposed
1. 720*480 31.469 / 31.5 59.94 / 60 27.00/27.03 SDTV 480P
2. 720*576 31.25 50 54 SDTV 576P
3. 1280*720 37.500 50 74.25 HDTV 720P
4. 1280*720 44.96 / 45 59.94 / 60 74.17/74.25 HDTV 720P
5. 1920*1080 33.72 / 33.75 59.94 / 60 74.17/74.25 HDTV 1080I
6. 1920*1080 28.125 50.00 74.25 HDTV 1080I
7. 1920*1080 26.97 / 27 231.97 / 24 74.17/74.25 HDTV 1080P FHD model
8. 1920*1080 33.716 / 33.75 29.976 / 30.00 74.25 HDTV 1080P FHD model
9. 1920*1080 56.250 50 148.5 HDTV 1080P FHD model
10. 1920*1080 67.43 / 67.5 59.94 / 60 148.35/148.50 HDTV 1080P FHD model
6.2. PC mode
No. Resolution H-freq.(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Proposed
1. 720*400 31.468 70.08 28.321 HDCP
2. 640*480 31.469 59.94 25.17 VESA HDCP
3. 800*600 37.879 60.31 40.00 VESA HDCP
4. 1024*768 48.363 60.00 65.00 VESA(XGA) HDCP
5. 1360*768 47.72 59.8 84.75 WXGA HDCP
6. 1280*1024 63.595 60.0 108.875 SXGA HDCP / FHD model
7. 1920*1080 67.5 60.00 138.625 WUXGA HDCP / FHD model
