LG LTNS16121V /00 - Page 33

°C °F
-26.0 -14.8 104.60 4.56
-24.0 -11.2 94.30 4.52
-22.0 -7.6 85.14 4.47
-20.0 -4.0 76.96 4.43
-18.0 -0.4 69.66 4.37
-16.0 3.2 63.13 4.32
-14.0 6.8 57.29 4.26
-12.0 10.4 52.05 4.19
-10.0 14.0 47.34 4.13
-8.0 17.6 43.12 4.06
-6.0 21.2 39.31 3.99
-4.0 24.8 35.88 3.91
-2.0 28.4 32.79 3.83
0.0 32.0 30.00 3.75
2.0 35.6 27.47 3.67
4.0 39.2 25.19 3.58
6.0 42.8 23.12 3.49
8.0 46.4 21.24 3.40
10.0 50.0 19.53 3.31
12.0 53.6 17.98 3.21
14.0 57.2 16.57 3.12
16.0 60.8 15.28 3.02
18.0 64.4 14.10 2.93
20.0 68.0 13.03 2.83
22.0 71.6 12.05 2.73
24.0 75.2 11.16 2.64
26.0 78.8 10.34 2.54
28.0 82.4 9.59 2.45
30.0 86.0 8.90 2.35
32.0 89.6 8.26 2.26
34.0 93.2 7.68 2.17
36.0 96.8 7.15 2.08
Temperature
Resistence (k ) Voltage (V)*
7-2 RESISTENCE, VOLTAGE & SPECIFIC TEMPERATURE FOR SENSORS
Sensors “RT” (Ambien Temperature)
33
REMARKS:
1. The sensor resistance has a variation of + 5%
2. Sensor resistance measurement must be done after 3 minutes since the sensor has been exposed to that temperature,
this is necessary for getting a reliable value.
3. For checking voltage, make sure of connection for PCB connector.
