- Defrost Sensor Error
1
2
3
Check if there’s a connector loose on CON8.
39
In the freezer compartment remove the
ventilator and check the resistance points
(orange wires).
No Checking Result and SVC countermeasure
Result SVC Support
Connected
Go to step 2.
Loose
Connect firmly and check again.
Is there a problem?
Yes: Go to step 2.
No: Explain to customer.
0
Short
Go to step 3.
OFF Open
Other Normal
1. Check temperature and resistance
(see chart of section 7-2).
2. Go to step 4.
Result
SVC Support
0
Short
OFF
Open
Other Normal
Change sensor harness.
Result
SVC Support
1. Check temperature and resistance
(see chart of section 7-2).
2. Place multi duct in its original
position.
3. Go to step 4.
Unplugged the refrigerator and all the PCB
connectors, check the resistance between
orange wires for CON8.
Image represents error
on display
