- Ambient Temperature Sensor Error
1
2
3
0 Short Replace the product
OFF Open Change sensor
41
1. Remove the cover from the upper hinge.
2. Cut the sensor and check the resistance
value of the cabinet side.
No Checking Result and SVC countermeasure
Check if there’s a connector loose on CON8.
Result
SVC Support
Connected
Go to step 2.
Loose
Connect firmly and check again.
Is there a problem?
Yes: Go to step 2.
No: Explain to customer.
Unplugged the refrigerator and all the PCB
connectors, check the resistance between
gray wires for CON8.
0
Short
Go to step 3.
OFF Open
Other Normal
1. Check temperature and resistance
(see chart of section 7-2).
2. Go to step 4.
Result
SVC Support
Go to step 4.
Result SVC Support
Image represents error
on display (when you
press the button for
1 second)
To Next Page
