LG M1721A User Manual

11
Name and Function of the Parts
Rear View
Power Connector : Connect the power cord.
Component Input Terminal
D-Sub Analog Signal Connector
RGB Sound Jack : Connect to the jack in the PC sound card or D-TV sound Output Jack.
TV Tuner Jack : Connect the antenna.
AV Input Terminal
Headphone/Earphone Connection Terminal
H/PS-VIDEO
AV IN
(Mono)
RGB (PC/DTV) IN
ANTENNA IN
AUDIO
(RGB) IN
VIDEO
AUDIO
VIDEO
AUDIO
L R
COMPONENT IN
Y
PB PR
LR
H/PS-VIDEO
AV IN
(Mono)
RGB (PC/DTV) IN
ANTENNA IN
AUDIO
(RGB) IN
VIDEO
AUDI O
VIDEO
AUDI O
L R
COMPONENT IN
Y
PB PR
LR
[19 inch]
[17 inch]
H/PS-VIDEO
AV IN
(Mono)
RGB (PC/DTV) IN
ANTENNA IN
AUDIO
(RGB) IN
VIDEO
AUDIO
VIDEO
AUDIO
L
R
Y
PB PR
LR
COMPONENT IN

LG M1721A Specifications

General

Audio system	stereo
RMS rated power	3 W
Number of speakers	2
Display	LCD
Power requirements	90 - 264 V AC, 47 - 63 Hz
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
HD type	SXGA
Display diagonal	17 \
Display brightness	300 cd/m²
Display resolution	1280 x 1024 pixels
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
SCART ports quantity	1
Product color	Black
Power consumption (typical)	45 W

Weight and Dimensions

Depth (without stand)	243 mm
Width (without stand)	394 mm
Height (without stand)	404 mm
Weight (without stand)	4500 g
