Specification

Remark

Resolution H-freq(kHz) V-freq(Hz) Pixel clock( MHz)

1. 720* 480 15.73 59.94 13.500 SDTV, DVD 480I( 525I)

2. 720* 480 15.75 60.00 13.514 SDTV, DVD 480I( 525I)

3. 720* 576 15.625 50.00 13.500 SDTV, DVD 576I( 625I) 50Hz

4. 720* 480 31.47 59.94 27.000 SDTV 480P

5. 720* 480 31.50 60.00 27.027 SDTV 480P

6. 720* 576 31.25 50.00 27.000 SDTV 576P 50Hz

7. 1280* 720 44.96 59.94 74.176 HDTV 720P

8. 1280* 720 45.00 60.00 74.250 HDTV 720P

9. 1280* 720 37.50 50.00 74.25 HDTV 720P 50Hz

10. 1920* 1080 33.72 59.94 74.176 HDTV 1080I

11. 1920* 1080 33.75 60.00 74.250 HDTV 1080I

12. 1920* 1080 28.125 50.00 74.250 HDTV 1080I 50Hz,

13. 1920* 1080 56.25 50 148.5 HDTV 1080P

14. 1920* 1080 67.432 59.94 148.350 HDTV 1080P

15. 1920* 1080 67.5 60.00 148.5 HDTV 1080P

9. Component Video Input (Y, PB , PR)

10. RGB/DVI INPUT (PC)

10.1 EDID Data (Product ID : 22349)

No. Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz) Remark

1. 720* 400 31.468 70.08 28.321

2. 640* 480 31.469 59.94 25.175

3. 640* 480 37.5 75 31.5

4. 800* 600 37.879 60.317 40.0

5. 800* 600 46.875 75.0 49.5

6. 1024* 768 48.363 60.0 65.0

7. 1024* 768 60.123 75.029 78.75

8. 1152* 864 67.500 75.000 108.0

9. 1280* 1024 63.981 60.02 108.0

10. 1280* 1024 79.976 75.035 135.0

11. 1680* 1050 64.674 59.883 119.0

12. 1680* 1050 65.290 59.954 146.25

13. 1600* 1200 75.0 60.0 162.0

14. 1920* 1080 66.587 59.934 138.5
