11. HDMI INPUT(DTV)

No. Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz) Remark

1 720* 480 31.469 / 31.5 59.94 / 60 23.00/ 23.03 SDTV 480P

2 720* 576 31.25 50 54 SDTV 576P

3 1280* 720 37.500 50 74.25 HDTV 720P

4 1280* 720 44.96 / 45 59.94 / 60 74.17/ 74.25 HDTV 720P

5 1920* 1080 33.72 / 33.75 59.94 / 60 74.17/ 74.25 HDTV 1080I

6 1920* 1080 28.125 50.00 74.25 HDTV 1080I

7 1920* 1080 26.97 / 23 23.97 / 24 74.17/ 74.25 HDTV 1080P

8 1920* 1080 33.716 / 33.75 29.976 / 30.00 74.25 HDTV 1080P

9 1920* 1080 56.250 50 148.5 HDTV 1080P

10 1920* 1080 67.43 / 67.5 59.94 / 60 148.35/ 148.50 HDTV 1080P

11.1 EDID Data (Product ID :22350)
