8.3 RGB INPUT MODE
NO Item Min Typ Max Unit Remark
1 Brightness uniformity 77 % Full white
Color Purity RED X 0.609 0.639 0.669 Input : 255 Level
Y 0.303 0.333 0.363 Picture mode : Standard
GREEN X 0.255 0.285 0.315
Y 0.575 0.605 0.635
BLUE X 0.114 0.144 0.174
Y 0.035 0.065 0.095
WHITE X 0.249 0.279 0.309
(Before) Y 0.262 0.292 0.322
Color WHITE X 0.261 0.276 0.291
coordinate (After) Y 0.268 0.283 0.298
* Standard Measurement Condition
• Ambient Luminance Level : dark ( < 10 lux)
• Ambient Temperature : Normal Temperature( 25+/- 2 °C)
• warm-up Time : About 30min (at Full White Pattern)
• Input Signal : V Frequency 60Hz, Dclk 65MHz
• Contrast : Default Value (100)
• Brightness : Default Value(64)
• 6500K : Color Temperature Setting is 6500 K( if it’s not special specification)
• Clock/Clock Phase : The Best Setting
* Another Spec.: Product Specification Standard( LG(55)G1-1034 )
* Cosmetic Spec. : LCD Module IIS Spec.
8.4 Display Area
8.4.1 Active Display Area of the LCD Monitor Should be within Cabinet’s Bezel .
8.4.2 Distance Difference between Active Area and Bezel
| A-B|< 1.5 mm , | C-D|< 1.5 mm
A: The Distance from The Left of Active Area to the Bezel
B: The Distance from The Right of Active Area to the Bezel
C: The Distance from The Top of Active Area to the Bezel
D: The Distance from The Bottom of Active Area to the Bezel
C
B
D
A
Active Area
Bezel
