Page #7 background imageLoading...
Page #7 background image
- 7 -
Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
C
2008
1. Application Range.
This spec sheet is applied to the 42” LCD Monitor TV used
LW81B chassis.
2. Specification
Each part is tested as below without special appointment
2.1 Temperature : 25±5°C(77±9°F), CST : 40±5°C
2.2 Relative Humidity : 65±10%
2.3 Power Voltage : Standard input voltage
(100~240V@ 50/60Hz)
• Standard Voltage of each products is marked by models
2.4 Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM .
2.5 The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
3.1 Performance : LGE TV test method followed.
3.2 Demanded other specification
Safety : CE, IEC specification
EMC : CE, IEC
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
4. General Specification
No Item Content Remark
1
Customer
BRAND
2
User Model Name
M4224C
3
Sale region
World wide
4
Feature
42 Commercial AV LCD Multi Function Monitor
5
Chassis Name
LW 81B
External SW
&Adj.
Source, Menu, , , , , Auto/Set, Power
6
General
Scope
Function
A/V In/Out, Component(HDTV Ready)x1, RGB IN/OUT, PC
Sound IN, RS232C In/out , HDMI (with HDCP),
Wired Control,
DDC2B
, LAN control
8Keys
7
Power Cord
Length : 1.87 0.04 M
Shape : Wall-out,
Color : Black (GRAY)
P/No
6410TKW005A
(6410TKW005B)
8
Cable
Signal
Cable (D-SUB)
Length : 1.87 0.04 M
Shape : Detachable Type
Color : GRAY (Black)
Pin : Triple Row, 15-Position Sub -miniature D
P/No.
6850TD9007E
(6850TD9007D)
Maker
Type TFT Color LCD Module
Active Display Area 42.02 i nches(1067.31mm) diagonal
Pixel Pitch [mm] 0.4845mm(H) 0.48 45mm(V)
Electrical Interface LVDS
Color Depth 10bits(D), 1.06 Billion
Size [mm] 956.4(H)x 549.4(V)x 53.5(D)
Surface Treatment Anti-Glare, Hard Coating (3H)
Operating Mode Normally Black,
Back light Unit 20 CCFL
9
LCD Module Feature
R/T
Typ 9ms(GTG)
P/No:EAJ51595601
(LD420WUB- SAA1)
LPL
