- 13 -
2. PC Mode(HDMI/DVI Input)
MODE SECTION POLA DOT CLOCK Frequency TOTAL Display Front Sync. Back RESOLUTION
RITY [MHz] [kHz]/[Hz] CYCLE (E) [A] Porch[B] [D] Porch[F]
1 H(Pixels) - 25.175 31.469 800 640 16 96 48 640 x480
V(Lines) - 59.94 525 480 10 2 33
2 H(Pixels) + 40.06 37.879 1056 800 40 128 88 800 x600
V(Lines) + 60.317 628 600 1 4 23
3 H(Pixels) - 65.0 48.363 1344 1024 24 136 160 1024 x768
V(Lines) - 60.0 806 768 3 6 29
4 H(Pixels) + 74.5 44.772 1664 1280 64 128 192 1280 x720
V(Lines) + 59.855 748 720 3 5 20
5 H(Pixels) + 80.14 47.7 1680 1280 64 136 200 1280 x768
V(Lines) + 60 795 768 1 3 23
6 H(Pixels) + 84.75 47.72 1776 1360 72 136 208 1360 x768
V(Lines) + 59.799 798 768 3 5 22
7 H(Pixels) - 85.86 47.7 1800 1366 72 144 216 1366 x768
V(Lines) - 60 795 768 1 3 23
8 H(Pixels) + 108.0 63.981 1688 1280 48 112 248 1280 x1024
V(Lines) + 60.02 1066 1024 1 3 38
9 H(Pixels) - 146.25 65.290 2240 1680 104 176 280 1680 x1050
V(Lines) + 59.954 1089 1050 3 6 30
10 H(Pixels) + 148.50 67.5 2200 1920 88 44 88 1920 x1080
V(Lines) + 60 1125 1080 4 5 46
3. COMPONENT INPUT(Y/Pb/Pr)
NO Resolution H-freq(kHz) V-freq(Hz)
1. 720*480 15.63 59.94 SDTV, DVD 480i
2. 720*483 31.47 59.94 EDTV 480p
3. 720*576 15.625 50.00 SDTV, DVD 625 Line
4. 720*576 31.25 50.00 HDTV 576p
5. 1280*720 45.00 60.00 HDTV 720p
6. 1280*720 37.5 50 HDTV 720p
7. 1280*720 44.96 59.94 HDTV 720p
8. 1920*1080 31.25 50.00 HDTV 1080i 50Hz (only AU)
9. 1920*1080 33.75 60.00 HDTV 1080i 60Hz (ATSC)
10. 1920*1080 33.72 59.94 HDTV 1080i 59.94Hz
11. 1920*1080 67.5 60 HDTV 1080P 60Hz
NO Resolution H-freq(kHz) V-freq(Hz)
1. 480/60P 31.5 60 EDTV 480p
2. 720/60P 45 60 HDTV 720p
3. 1080/60i 33.75 60 HDTV 1080i 60Hz (ATSC)
4. 576/50P 31.25 50.00 HDTV 576p
5. 720/50P 37.5 50 HDTV 720p
6. 1080/50i 28.1 50 HDTV 1080i 50Hz (only AU)
7. 1080/60P 67.5 60 HDTV 1080P 60Hz
4 HDMI/DVI-DTV
