7. Engineering Specification
No. SECTION CONTENTS REMARK
1. Supported Sync Type Separate Sync, SOG, Composite Sync, Digital
2 Operating Frequency Analog Horizontal 30 ~ 83 KHz
Vertical 56 ~ 75 Hz
Digital Horizontal 30 ~ 83 KHz
Vertical 56 ~ 60 Hz
3 Resolution Analog Max 1920 x 1080 @60Hz
Recommend 1920 x 1080 @60Hz
Digital Max 1920 x 1080 @60Hz
Recommend 1920 x 1080 @60Hz
4 Input Voltage Voltage : 100 ~ 240Vac , 50 or 60Hz
Current Rating
5 Inrush Current Cold : 40A , Hot : 40A
6 Operating Condition Sync (H/V) Video LED Wattage
Normal Mode(1/8 point of
Normal (Typ) On/On Active Green 220W
max audio output)
Sleep Mode Stand by Off/On Off Amber 1W RGB
(Set = On) ( G Signal should be off) Off/On Off Amber 4W HDMI
(Signal=Off) Suspend On/Off Off Amber 1W RGB
( G Signalshould be off) On/Off Off Amber 4W HDMI
DPMS Off Off/Off Off Amber 1W RGB
( G Signal should be off) Off/Off Off Amber 4W HDMI
Deep Sleep Mode
Power SW Off Off/Off Off Off 1W
(Set = Off)
7 MTBF 50,000 HRS with 90%Lamp Life
Confidence level :50,000 Hours (min)
8 Using Altitude 5,000 m (for Reliability) 3,000 m (for FOS)
9 Environment Operating Temperature 5 °C ~ 35 °C
Condition Humidity 10% ~ 80%
Storage Temperature -20 °C ~ 60 °C non condensing
Humidity 5% ~ 95% non-condensing
