2-12
WAVEFORMS
1) MICOM(IC401) ↔ DISPLAY(CN402)
IC401:[PIN25]
IC401:[PIN23]
IC401:[PIN24]
IC401:[PIN29]
2) MICOM(IC401) ↔ TUNER IC(IC101)
IC401:[PIN2]
IC401:[PIN1]
3) MICOM(IC401) ↔ VOLUME IC(IC601)
IC401:[PIN32]
IC401:[PIN31]
