Heat Pump 50Hz/R410A _ 9
1. Multiple piping type MULTI F
Part 2 Product data_Outdoor units
Models : A2UW16GFA0 [MU2M17 UL2]
Cooling
Heating
Note :
1. Cooling Capacity is based on : indoor temp.27°CDB, 19°CWB
; outdoor temp. 35°CDB, 24°CWB
2. Heating Capacity is based on : indoor temp.20°CDB, 15°CWB
; outdoor temp. 7°CDB, 6°CWB
3. Maximum total capacity index of connected indoor units is 24 kBtu/h.
4. At least two indoor units should be connected to outdoor unit.
5. Total capacity of indoor units connected should be minimum 40% of outdoor unit rated capacity.
5 - 5 1.5 - 3,000 0.9 5,000 1.5 6,000 1.8 290 480 600
1 UNIT
7 - 7 2.1 - 4,200 1.2 7,000 2.1 8,400 2.5 320 520 620
9 - 9 2.6 - 5,400 1.6 9,000 2.6 10,800 3.2 400 660 850
12 - 12 3.5 - 7,200 2.1 12,000 3.5 14,400 4.2 530 880 1,220
5 5 10 1.5 1.5 6,000 1.8 10,000 2.9 11,500 3.4 480 800 1,090
5 7 12 1.5 2.1 7,200 2.1 12,000 3.5 13,800 4.0 530 880 1,220
5 9 14 1.5 2.6 8,400 2.5 14,000 4.1 16,100 4.7 620 1,020 1,450
5 12 17 1.4 3.3 9,600 2.8 16,000 4.7 18,400 5.4 760 1,260 1,630
2 UNIT 7 7 14 2.1 2.1 8,400 2.5 14,000 4.1 16,100 4.7 620 1,020 1,450
7 9 16 2.1 2.6 9,600 2.8 16,000 4.7 18,400 5.4 760 1,260 1,630
7 12 19 1.7 3.0 9,600 2.8 16,000 4.7 18,400 5.4 760 1,260 1,630
9 9 18 2.3 2.3 9,600 2.8 16,000 4.7 18,400 5.4 760 1,260 1,630
9 12 21 2.0 2.7 9,600 2.8 16,000 4.7 18,400 5.4 760 1,260 1,630
12 12 24 2.3 2.3 9,600 2.8 16,000 4.7 18,400 5.4 760 1,260 1,630
Combination
(kBtu/h)
Each capacity
(kW)
Total Capacity (kW)
Cooling
Min Rated Max
Input
(W)
Unit-A Unit-B Total Unit-A Unit-B Btu/h kW Btu/h kW Btu/h kW Min Rated Max
Operation
5 - 5 1.6 - 3,300 1.0 5,500 1.6 6,000 1.8 290 480 600
1 UNIT
7 - 7 2.5 - 5,100 1.5 8,400 2.5 9,200 2.7 340 560 710
9 - 9 3.2 - 6,500 1.9 10,800 3.2 11,800 3.5 420 700 890
12 - 12 3.9 - 8,000 2.3 13,200 3.9 14,500 4.2 520 860 1,120
5 5 10 1.6 1.6 6,600 1.9 11,000 3.2 12,100 3.5 450 740 940
5 7 12 1.6 2.3 8,000 2.3 13,200 3.9 14,500 4.2 520 860 1,090
5 9 14 1.7 3.0 9,600 2.8 16,000 4.7 17,200 5.0 650 1,080 1,390
5 12 17 1.6 3.7 10,800 3.2 18,000 5.3 19,400 5.7 770 1,280 1,660
2 UNIT 7 7 14 2.3 2.3 9,600 2.8 16,000 4.7 17,200 5.0 650 1,080 1,390
7 9 16 2.3 3.0 10,800 3.2 18,000 5.3 19,400 5.7 770 1,280 1,660
7 12 19 1.9 3.3 10,800 3.2 18,000 5.3 19,400 5.7 770 1,280 1,660
9 9 18 2.6 2.6 10,800 3.2 18,000 5.3 19,400 5.7 770 1,280 1,660
9 12 21 2.3 3.0 10,800 3.2 18,000 5.3 19,400 5.7 770 1,280 1,660
12 12 24 2.6 2.6 10,800 3.2 18,000 5.3 19,400 5.7 770 1,280 1,660
Combination
(kBtu/h)
Each capacity
(kW)
Total Capacity (kW)
Heating
Min Rated Max
Input
(W)
Unit-A Unit-B Total Unit-A Unit-B Btu/h kW Btu/h kW Btu/h kW Min Rated Max
Operation
