LG MULTI F A3UW21GFA0

Heat Pump 50Hz/R410A _ 13
1. Multiple piping type MULTI F
Part 2 Product data_Outdoor units
Heating
Note :
1. Cooling Capacity is based on : indoor temp.27°CDB, 19°CWB
; outdoor temp. 35°CDB, 24°CWB
2. Heating Capacity is based on : indoor temp.20°CDB, 15°CWB
; outdoor temp. 7°CDB, 6°CWB
3. Maximum total capacity index of connected indoor units is 33 kBtu/h.
4. At least two indoor units should be connected to outdoor unit.
5. Total capacity of indoor units connected should be minimum 40% of outdoor unit rated capacity.
5 - - 5 1.6 - - 5,000 1.5 5,500 1.6 6,050 1.8 210 407 648
7 - - 7 2.3 - - 7,560 2.2 8,000 2.3 8,800 2.6 210 570 907
1 Unit 9 - - 9 2.9 - - 7,560 2.2 10,000 2.9 10,900 3.2 378 733 1,166
12 - - 12 3.9 - - 7,920 2.3 13,200 3.9 14,500 4.2 504 977 1,554
18 - - 18 5.8 - - 11,880 3.5 19,800 5.8 21,800 6.4 756 1,466 2,331
5 5 - 10 1.6 1.6 - 6,600 1.9 11,000 3.2 12,100 3.5 420 814 1,295
5 7 - 12 1.6 2.5 - 8,340 2.4 13,900 4.1 15,290 4.5 504 977 1,554
5 9 - 14 1.6 2.9 - 9,300 2.7 15,500 4.5 18,500 5.4 588 1,140 1,813
7 7 - 14 2.5 2.5 - 10,080 3.0 16,800 4.9 18,500 5.4 588 1,140 1,813
7 9 - 16 2.5 3.2 - 11,520 3.4 19,200 5.6 21,100 6.2 672 1,303 2,072
5 12 - 17 1.6 3.9 - 11,220 3.3 18,700 5.5 23,700 6.9 714 1,384 2,202
2 Unit 9 9 - 18 3.2 3.2 - 12,960 3.8 21,600 6.3 23,700 6.9 756 1,466 2,331
7 12 - 19 2.5 4.2 - 13,680 4.0 22,800 6.7 25,000 7.3 798 1,547 2,461
9 12 - 21 3.2 4.2 - 15,120 4.4 24,000 7.0 26,500 7.8 882 1,710 2,720
5 18 - 23 1.6 5.8 - 15,180 4.4 24,000 7.0 26,500 7.8 882 1,710 2,720
12 12 - 24 3.9 3.9 - 15,840 4.6 24,000 7.0 26,500 7.8 882 1,710 2,720
7 18 - 25 2.3 5.9 - 16,680 4.9 24,000 7.0 26,500 7.8 882 1,710 2,720
9 18 - 27 2.8 5.6 - 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
12 18 - 30 3.4 5.1 - 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
5 5 5 15 1.6 1.6 1.6 9,900 2.9 16,500 4.8 18,150 5.3 630 1,221 1,943
5 5 7 17 1.6 1.6 2.5 11,640 3.4 19,400 5.7 21,340 6.3 714 1,384 2,202
5 5 9 19 1.6 1.6 2.9 12,600 3.7 21,000 6.2 23,100 6.8 798 1,547 2,461
5 7 7 19 1.6 2.5 2.3 13,140 3.9 21,900 6.4 24,090 7.1 798 1,547 2,461
5 7 9 21 1.6 2.5 2.9 14,340 4.2 24,000 7.0 26,500 7.8 882 1,710 2,720
7 7 7 21 2.5 2.5 2.5 15,120 4.4 24,000 7.0 26,500 7.8 882 1,710 2,720
5 5 12 22 1.6 1.6 3.9 14,520 4.3 24,000 7.0 26,500 7.8 882 1,710 2,720
7 7 9 23 2.5 2.5 3.2 16,560 4.9 24,000 7.0 26,500 7.8 882 1,710 2,720
5 9 9 23 1.6 2.9 2.9 15,300 4.5 24,000 7.0 26,500 7.8 882 1,710 2,720
5 7 12 24 1.8 2.5 4.2 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
7 9 9 25 2.4 3.0 3.0 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
3 Unit 5 9 12 26 1.6 2.9 3.9 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
7 7 12 26 2.3 2.3 3.9 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
9 9 9 27 2.8 2.8 2.8 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
7 9 12 28 2.1 2.7 3.6 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
5 5 18 28 1.5 1.5 5.4 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
5 12 12 29 1.5 3.5 3.5 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
5 7 18 30 1.4 2.0 5.1 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
9 9 12 30 2.5 2.5 3.4 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
7 12 12 31 1.9 3.3 3.3 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
5 9 18 32 1.3 2.4 4.7 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
7 7 18 32 1.8 1.8 4.7 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
9 12 12 33 2.3 3.1 3.1 17,280 5.1 24,000 7.0 26,500 7.8 882 1,710 2,720
Combination
(kBtu/h)
Each capacity
(kW)
Total Capacity (kW)
Heating
Min Rated Max
Input
(W)
Unit-A Unit-B Unit-C Total Unit-A Unit-B Unit-C Btu/h kW Btu/h kW Btu/h kW Min Rated Max
Operation
