Heat pump 50Hz/R410A _ 1
4. BD Unit (Distributor Box)
Part 2 Product data_Outdoor units
4.1 Specifications
Connectable indoor units Number of indoor units
Capacity Btu/h
Power source V, Ø, Hz
Power consumption W
Running current A
Dimension W x H x D mm
inch
Net weight kg
Connecting cable Direction indoor unit No. x mm
2
Direction outdoor unit No. x mm
2
Piping connection Liquid (Ø) mm(inch)
(To outdoor unit) Gas (Ø) mm(inch)
Piping connection Liquid (Ø) mm(inch)
(To indoor unit) Gas (Ø) mm(inch)
Accessories Hanger (Bracket) EA
Screw EA
Manual EA
1~2 1~3 1~4
5k/7k/9k/12k/18k/24k 5k/7k/9k/12k/18k/24k 5k/7k/9k/12k/18k/24k
220-240, 1, 50 220-240, 1, 50 220-240, 1, 50
10 10 10
0.05 0.05 0.05
302 x 143 x 252 302 x 143 x 252 302 x 143 x 252
11-7/8 x 5-5/8 x 9-29/32 11-7/8 x 5-5/8 x 9-29/32 11-7/8 x 5-5/8 x 9-29/32
4.8 4.9 5
4 x 0.75 (including earth) 4 x 0.75 (including earth) 4 x 0.75 (including earth)
4 x 1.25 (including earth) 4 x 1.25 (including earth) 4 x 1.25 (including earth)
9.52(3/8) 9.52(3/8) 9.52(3/8)
19.05(3/4) 19.05(3/4) 19.05(3/4)
6.35(1/4) x 2EA 6.35(1/4) x 3EA 6.35(1/4) x 4EA
9.52(3/8) x 2EA 9.52(3/8) x 3EA 9.52(3/8) x 4EA
444
888
111
PMBD3620 PMBD3630 PMBD3640
BD unit
Note :
1. BD unit or Indoor Unit Max. Height <--> BD unit or Indoor Unit Min. Height : Max.10m
Set up the BD unit and Indoor Unit in 15m.
2. The piping connection must be suit the piping sizes of the indoor unit which will be connected.
(If need, use the connector which is included in the indoor unit)
3. The BD should be installed inside the building.
4. Wiring cable size must comply with the applicable local and national code.
5. Multi Fdx 1Ø and Multi Fdx 3Ø apply to the same BD units (Branch distributor units)
