LG MULTI F A3UW21GFA0

Heat Pump 50Hz/R410A _ 15
1. Multiple piping type MULTI F
Part 2 Product data_Outdoor units
Note :
1. Cooling Capacity is based on : indoor temp.27°CDB, 19°CWB
; outdoor temp. 35°CDB, 24°CWB
2. Heating Capacity is based on : indoor temp.20°CDB, 15°CWB
; outdoor temp. 7°CDB, 6°CWB
3. Maximum total capacity index of connected indoor units is 39 kBtu/h.
4. At least two indoor units should be connected to outdoor unit.
5. Total capacity of indoor units connected should be minimum 40% of outdoor unit rated capacity.
5 5 5 5 20 1.5 1.5 1.5 1.5 12,000 3.5 20,000 5.9 24,000 7.0 852 1,420 1,971
5 5 5 7 22 1.5 1.5 1.5 2.1 13,200 3.9 22,000 6.4 26,400 7.7 924 1,540 2,206
5 5 5 9 24 1.5 1.5 1.5 2.6 14,400 4.2 24,000 7.0 28,500 8.4 990 1,670 2,510
5 5 7 7 24 1.5 1.5 2.1 2.1 14,400 4.2 24,000 7.0 28,500 8.4 990 1,670 2,510
5 5 7 9 26 1.4 1.4 1.9 2.4 14,400 4.2 24,000 7.0 28,500 8.4 990 1,670 2,510
5 7 7 7 26 1.4 1.9 1.9 1.9 14,400 4.2 24,000 7.0 28,500 8.4 990 1,670 2,510
5 5 5 12 27 1.3 1.3 1.3 3.1 14,400 4.2 24,000 7.0 28,500 8.4 990 1,670 2,510
5 5 9 9 28 1.3 1.3 2.3 2.3 14,400 4.2 24,000 7.0 28,500 8.4 990 1,670 2,510
5 7 7 9 28 1.3 1.8 1.8 2.3 14,400 4.2 24,000 7.0 28,500 8.4 990 1,670 2,510
7 7 7 7 28 1.8 1.8 1.8 1.8 14,400 4.2 24,000 7.0 28,500 8.4 990 1,670 2,510
5 5 7 12 29 1.2 1.2 1.7 2.9 14,400 4.2 24,000 7.0 28,500 8.4 990 1,670 2,510
5 7 9 9 30 1.2 1.6 2.1 2.1 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
7 7 7 9 30 1.6 1.6 1.6 2.1 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
5 5 9 12 31 1.1 1.1 2.0 2.7 14,400 4.2 24,000 7.0 28,500 8.4 990 1,670 2,590
5 7 7 12 31 1.1 1.6 1.6 2.7 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
7 7 9 9 32 1.5 1.5 2.0 2.0 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
5 9 9 9 32 1.1 2.0 2.0 2.0 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
4 UNIT 5 5 5 18 33 1.1 1.1 1.1 3.8 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
5 7 9 12 33 1.1 1.5 1.9 2.6 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
7 7 7 12 33 1.5 1.5 1.5 2.6 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
5 5 12 12 34 1.0 1.0 2.5 2.5 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
7 9 9 9 34 1.4 1.9 1.9 1.9 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
5 5 7 18 35 1.0 1.0 1.4 3.6 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
5 9 9 12 35 1.0 1.8 1.8 2.4 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
7 7 9 12 35 1.4 1.4 1.8 2.4 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
5 7 12 12 36 1.0 1.4 2.3 2.3 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
9 9 9 9 36 1.8 1.8 1.8 1.8 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
5 5 9 18 37 1.0 1.0 1.7 3.4 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
5 7 7 18 37 1.0 1.3 1.3 3.4 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
7 9 9 12 37 1.3 1.7 1.7 2.3 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
7 7 12 12 38 1.3 1.3 2.2 2.2 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
5 5 5 24 39 0.9 0.9 0.9 4.3 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
5 7 9 18 39 0.9 1.3 1.6 3.2 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
9 9 9 12 39 1.6 1.6 1.6 2.2 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
7 7 7 18 39 1.3 1.3 1.3 3.2 14,400 4.2 24,000 7.0 29,000 8.5 990 1,670 2,590
Combination
(kBtu/h)
Each capacity
(kW)
Total Capacity (kW)
Cooling
Min Rated Max
Input
(W)
Unit-A Unit-B Unit-C Unit-D Total Unit-A Unit-B Unit-C Unit-D Btu/h kW Btu/h kW Btu/h kW Min Rated Max
Operation
