Heat Pump
50Hz/R410A _ 29
1. Multiple piping type MULTI F
Part 2 Product data_Outdoor units
5 12 24 - - 41 1.4 3.3 6.6 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
5 18 18 - - 41 1.4 4.9 4.9 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
12 12 18 - - 42 3.2 3.2 4.8 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
9 9 24 - - 42 2.4 2.4 6.4 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
7 18 18 - - 43 1.8 4.7 4.7 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
7 12 24 - - 43 1.8 3.1 6.2 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
9 18 18 - - 45 2.2 4.5 4.5 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
9 12 24 - - 45 2.2 3.0 6.0 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
5 18 24 - - 47 1.2 4.3 5.7 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
12 18 18 - - 48 2.8 4.2 4.2 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
12 12 24 - - 48 2.8 2.8 5.6 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
7 18 24 - - 49 1.6 4.1 5.5 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
9 18 24 - - 51 2.0 4.0 5.3 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
5 5 5 5 - 20 1.5 1.5 1.5 1.5 - 12,000 3.5 20,000 5.9 24,000 7.0 868 1,400 2,128
5 5 5 7 - 22 1.5 1.5 1.5 2.1 - 13,200 3.9 22,000 6.4 26,400 7.7 955 1,540 2,341
5 5 5 9 - 24 1.5 1.5 1.5 2.6 - 14,400 4.2 24,000 7.0 28,800 8.4 1,042 1,680 2,554
5 5 7 7 - 24 1.5 1.5 2.1 2.1 - 14,400 4.2 24,000 7.0 28,800 8.4 1,042 1,680 2,554
5 5 7 9 - 26 1.5 1.5 2.1 2.6 - 15,600 4.6 26,000 7.6 31,200 9.1 1,128 1,820 2,767
5 7 7 7 - 26 1.5 2.1 2.1 2.1 - 15,600 4.6 26,000 7.6 31,200 9.1 1,128 1,820 2,767
5 5 5 12 - 27 1.5 1.5 1.5 3.5 - 16,200 4.7 27,000 7.9 32,400 9.5 1,172 1,890 2,873
5 5 9 9 - 28 1.5 1.5 2.6 2.6 - 16,800 4.9 28,000 8.2 33,600 9.8 1,215 1,960 2,979
5 7 7 9 - 28 1.5 2.1 2.1 2.6 - 16,800 4.9 28,000 8.2 33,600 9.8 1,215 1,960 2,979
7 7 7 7 - 28 2.1 2.1 2.1 2.1 - 16,800 4.9 28,000 8.2 33,600 9.8 1,215 1,960 2,979
5 5 7 12 - 29 1.5 1.5 2.1 3.5 - 17,400 5.1 29,000 8.5 34,800 10.2 1,259 2,030 3,086
5 7 9 9 - 30 1.5 2.1 2.6 2.6 - 18,000 5.3 30,000 8.8 36,000 10.6 1,302 2,100 3,192
7 7 7 9 - 30 2.1 2.1 2.1 2.6 - 18,000 5.3 30,000 8.8 36,000 10.6 1,302 2,100 3,192
5 5 9 12 - 31 1.5 1.5 2.6 3.5 - 18,600 5.5 31,000 9.1 37,200 10.9 1,345 2,170 3,299
5 7 7 12 - 31 1.5 2.1 2.1 3.5 - 18,600 5.5 31,000 9.1 37,200 10.9 1,345 2,170 3,299
7 7 9 9 - 32 2.1 2.1 2.6 2.6 - 19,200 5.6 32,000 9.4 38,400 11.3 1,389 2,240 3,405
5 9 9 9 - 32 1.5 2.6 2.6 2.6 - 19,200 5.6 32,000 9.4 38,400 11.3 1,389 2,240 3,405
5 5 5 18 - 33 1.5 1.5 1.5 5.3 - 19,800 5.8 33,000 9.7 39,600 11.6 1,432 2,310 3,512
5 7 9 12 - 33 1.5 2.1 2.6 3.5 - 19,800 5.8 33,000 9.7 39,600 11.6 1,432 2,310 3,512
7 7 7 12 - 33 2.1 2.1 2.1 3.5 - 19,800 5.8 33,000 9.7 39,600 11.6 1,432 2,310 3,512
5 5 12 12 - 34 1.5 1.5 3.5 3.5 - 20,400 6.0 34,000 10.0 40,800 12.0 1,476 2,380 3,618
7 9 9 9 - 34 2.1 2.6 2.6 2.6 - 20,400 6.0 34,000 10.0 40,800 12.0 1,476 2,380 3,618
5 5 7 18 - 35 1.5 1.5 2.1 5.3 - 21,000 6.2 35,000 10.3 42,000 12.3 1,519 2,450 3,724
5 9 9 12 - 35 1.5 2.6 2.6 3.5 - 21,000 6.2 35,000 10.3 42,000 12.3 1,519 2,450 3,724
7 7 9 12 - 35 2.1 2.1 2.6 3.5 - 21,000 6.2 35,000 10.3 42,000 12.3 1,519 2,450 3,724
5 7 12 12 - 36 1.5 2.1 3.5 3.5 - 21,600 6.3 36,000 10.6 43,200 12.7 1,562 2,520 3,831
9 9 9 9 - 36 2.6 2.6 2.6 2.6 - 21,600 6.3 36,000 10.6 43,200 12.7 1,562 2,520 3,831
5 5 9 18 - 37 1.5 1.5 2.6 5.3 - 22,200 6.5 37,000 10.8 44,400 13.0 1,606 2,590 3,937
5 7 7 18 - 37 1.5 2.1 2.1 5.3 - 22,200 6.5 37,000 10.8 44,400 13.0 1,606 2,590 3,937
7 9 9 12 - 37 2.1 2.6 2.6 3.5 - 22,200 6.5 37,000 10.8 44,400 13.0 1,606 2,590 3,937
7 7 12 12 - 38 2.1 2.1 3.5 3.5 - 22,800 6.7 38,000 11.1 45,600 13.4 1,649 2,660 4,044
5 5 5 24 - 39 1.4 1.4 1.4 6.9 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
5 7 9 18 - 39 1.4 2.0 2.6 5.2 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
9 9 9 12 - 39 2.6 2.6 2.6 3.4 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
7 7 7 18 - 39 2.0 2.0 2.0 5.2 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
7 9 12 12 - 40 2.0 2.5 3.4 3.4 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
5 5 7 24 - 41 1.4 1.4 1.9 6.6 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
5 12 12 12 - 41 1.4 3.3 3.3 3.3 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
7 7 9 18 - 41 1.9 1.9 2.5 4.9 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
9 9 12 12 - 42 2.4 2.4 3.2 3.2 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
7 12 12 12 - 43 1.8 3.1 3.1 3.1 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
7 9 9 18 - 43 1.8 2.3 2.3 4.7 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
7 7 12 18 - 44 1.8 1.8 3.1 4.6 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
9 12 12 12 - 45 2.2 3.0 3.0 3.0 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
9 9 9 18 - 45 2.2 2.2 2.2 4.5 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
7 7 7 24 - 45 1.7 1.7 1.7 6.0 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
7 9 12 18 - 46 1.7 2.2 2.9 4.4 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
5 5 18 18 - 46 1.2 1.2 4.4 4.4 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
5 12 12 18 - 47 1.2 2.9 2.9 4.3 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
7 7 9 24 - 47 1.7 1.7 2.1 5.7 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
5 7 18 18 - 48 1.2 1.6 4.2 4.2 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
12 12 12 12 - 48 2.8 2.8 2.8 2.8 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
9 9 12 18 - 48 2.1 2.1 2.8 4.2 - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
Combination
(kBtu/h)
Each capacity
(kW)
Total Capacity (kW)
Cooling
Min Rated Max
Input
(W)
Unit-A Unit-B Unit-C Unit-D Unit-E Total Unit-A Unit-B Unit-C Unit-D Unit-E Btu/h kW Btu/h kW Btu/h kW Min Rated Max
Operation
3 UNIT
4 UNIT
