1. Multiple piping type MULTI F
68 _ Heat Pump 50Hz/R410A
Part 2 Product data_Outdoor units
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
Combination
capacity index
(kBtu/h)
Outdoor
air temp.:
(°CDB)
Operation
14 16 18 19 22 24
Indoor air temp.: (°CWB)
Notes:
1. Capacities are based on the following conditions.
Corresponding refrigerant piping length : 7.5m
Level difference : 0m
2. TC : Total Capacity (kW)
PI : Power Input (kW)
5+9+18
7+7+18
9+12+12
22 5.99 0.86 6.37 1.16 6.74 1.26 6.93 1.27 7.49 1.28 7.87 1.28
25 5.85 0.91 6.22 1.19 6.60 1.29 6.79 1.31 7.35 1.33 7.72 1.34
32 5.52 1.22 5.89 1.44 6.27 1.52 6.46 1.53 7.02 1.57 7.39 1.60
35 5.38 1.37 5.75 1.55 6.13 1.61 6.30 1.58 6.88 1.66 7.25 1.69
40 5.14 1.50 5.52 1.62 5.89 1.64 6.08 1.64 6.64 1.67 7.02 1.70
43 5.00 1.47 5.38 1.54 5.75 1.54 5.94 1.53 6.50 1.55 6.88 1.58
46 4.86 1.32 5.23 1.33 5.61 1.30 5.80 1.29 6.36 1.29 6.73 1.32
22 5.99 0.86 6.37 1.16 6.74 1.26 6.93 1.27 7.49 1.28 7.87 1.28
25 5.85 0.91 6.22 1.19 6.60 1.29 6.79 1.31 7.35 1.33 7.72 1.34
32 5.52 1.22 5.89 1.44 6.27 1.52 6.46 1.53 7.02 1.57 7.39 1.60
35 5.38 1.37 5.75 1.55 6.13 1.61 6.30 1.58 6.88 1.66 7.25 1.69
40 5.14 1.50 5.52 1.62 5.89 1.64 6.08 1.64 6.64 1.67 7.02 1.70
43 5.00 1.47 5.38 1.54 5.75 1.54 5.94 1.53 6.50 1.55 6.88 1.58
46 4.86 1.32 5.23 1.33 5.61 1.30 5.80 1.29 6.36 1.29 6.73 1.32
22 5.99 0.86 6.37 1.16 6.74 1.26 6.93 1.27 7.49 1.28 7.87 1.28
25 5.85 0.91 6.22 1.19 6.60 1.29 6.79 1.31 7.35 1.33 7.72 1.34
32 5.52 1.22 5.89 1.44 6.27 1.52 6.46 1.53 7.02 1.57 7.39 1.60
35 5.38 1.37 5.75 1.55 6.13 1.61 6.30 1.58 6.88 1.66 7.25 1.69
40 5.14 1.50 5.52 1.62 5.89 1.64 6.08 1.64 6.64 1.67 7.02 1.70
43 5.00 1.47 5.38 1.54 5.75 1.54 5.94 1.53 6.50 1.55 6.88 1.58
46 4.86 1.32 5.23 1.33 5.61 1.30 5.80 1.29 6.36 1.29 6.73 1.32
3 units
