LG MULTI V ARNU54GTMA4 - Page 269

14 _ Ceiling Concealed Duct(Low Static)
Indoor Units
Indoor unit
6. Capacity Tables
Heating capacity
Notes:
TC: Total Capacity(kW)
1. Capacity tables show the representative value of conditions which may occur.
2. is shown as reference. When selecting the outdoor units, avoid the out-
door air temperature range shown by
.
3. In accordance with operation limits of outdoor unit, applicable range of capac-
ity tables is different.
4. Refer to Capacity Correction Factorin the outdoor unit PDBfor the actual per-
formance data of each indoor unitand outdoor unit combination.
Capacity
Index
Outdoor air
temp.
DB(°C) WB(°C)
Indoor air temp. (DB, °C)
16 18 20 21 22 24
TC TC TC TC TC TC
kW kW kW kW kW kW
-24.8 -25.0 4.1 4.1 4.0 4.0 4.0 4.0
-21.8 -22.0 4.9 4.9 4.9 4.9 4.9 4.8
-19.8 -20.0 5.2 5.2 5.1 5.1 5.1 5.1
-18.8 -19.0 5.3 5.2 5.2 5.2 5.2 5.2
-16.7 -17.0 5.5 5.5 5.5 5.5 5.5 5.5
-14.7 -15.0 5.8 5.8 5.8 5.8 5.8 5.7
-12.6 -13.0 6.1 6.0 6.0 6.0 6.0 6.0
-10.5 -11.0 6.3 6.3 6.3 6.3 6.3 6.1
-9.5 -10.0 6.5 6.5 6.4 6.4 6.4 6.1
-8.5 -9.1 6.6 6.6 6.5 6.5 6.5 6.1
-7.0 -7.6 6.8 6.7 6.7 6.7 6.6 6.1
-5.0 -5.6 7.0 7.0 7.0 6.8 6.6 6.1
-3.0 -3.7 7.4 7.2 7.0 6.8 6.6 6.1
0.0 -0.7 7.5 7.2 7.0 6.8 6.6 6.1
3.0 2.2 7.7 7.4 7.0 6.8 6.6 6.1
5.0 4.1 7.8 7.4 7.0 6.8 6.6 6.1
7.0 6.0 7.9 7.4 7.0 6.8 6.6 6.1
9.0 7.9 7.9 7.4 7.0 6.8 6.6 6.1
11.0 9.8 7.9 7.4 7.0 6.8 6.6 6.1
13.0 11.8 7.9 7.4 7.0 6.8 6.6 6.1
15.0 13.7 7.9 7.4 7.0 6.8 6.6 6.1
6.2
-24.8 -25.0 4.6 4.6 4.6 4.6 4.6 4.6
-21.8 -22.0 5.6 5.6 5.6 5.6 5.6 5.5
-19.8 -20.0 5.9 5.9 5.9 5.9 5.9 5.8
-18.8 -19.0 6.0 6.0 6.0 6.0 6.0 6.0
-16.7 -17.0 6.3 6.3 6.3 6.3 6.3 6.3
-14.7 -15.0 6.6 6.6 6.6 6.6 6.6 6.6
-12.6 -13.0 6.9 6.9 6.9 6.9 6.9 6.9
-10.5 -11.0 7.2 7.2 7.2 7.2 7.2 7.0
-9.5 -10.0 7.4 7.4 7.3 7.3 7.3 7.0
-8.5 -9.1 7.5 7.5 7.5 7.5 7.5 7.0
-7.0 -7.6 7.7 7.7 7.7 7.7 7.5 7.0
-5.0 -5.6 8.0 8.0 8.0 7.7 7.5 7.0
-3.0 -3.7 8.4 8.2 8.0 7.7 7.5 7.0
0.0 -0.7 8.6 8.3 8.0 7.7 7.5 7.0
3.0 2.2 8.8 8.5 8.0 7.7 7.5 7.0
5.0 4.1 8.9 8.5 8.0 7.7 7.5 7.0
7.0 6.0 9.0 8.5 8.0 7.7 7.5 7.0
9.0 7.9 9.0 8.5 8.0 7.7 7.5 7.0
11.0 9.8 9.0 8.5 8.0 7.7 7.5 7.0
13.0 11.8 9.0 8.5 8.0 7.7 7.5 7.0
15.0 13.7 9.0 8.5 8.0 7.7 7.5 7.0
7.1
