LG MULTI V WATER IV ARWN LAS4 Series Installation Manual

Outside units Information
10 Outside Unit
Unit 2 Unit
System Capacity (HP) 34 36
Model
Combination Unit
ARWN340LAS4 ARWN360LAS4
Independent Unit
ARWN200LAS4
ARWN140LAS4
ARWN180LAS4
ARWN180LAS4
Refrigerant Precharged Amount kg
3.0 + 5.8 3.0 + 3.0
Maximum Connectable Number of Indoor Units 55 58
Net Weight
kg
(140 x 1) + (127 x 1) 140 x 2
lbs
(309 x 1) + (280 x 1) 309 x 2
Dimensions(WxHxD)
mm
(755 × 997 × 500) x 2 (755 × 997 × 500) x 2
inch
(29-23/32 x 39-1/4 x 19-11/16) x 2 (29-23/32 x 39-1/4 x 19-11/16) x 2
Refrigerant
Connecting Pipes
Liquid mm(inch)
19.05(3/4) 19.05(3/4)
Gas mm(inch)
34.9(1-3/8) 41.3(1-5/8)
Water Connecting
Pipes
Inlet mm
PT 40 + PT 40 PT 40 + PT 40
Outlet mm
PT 40 + PT 40 PT 40 + PT 40
Drain Outlet mm
20 20
Temp. range of
Circulation water
Cooling
10°C ~ 45°C(50°F ~ 113°F) 10°C ~ 45°C(50°F ~ 113°F)
Heating
-5°C ~ 45°C(23°F ~ 113°F) -5°C ~ 45°C(23°F ~ 113°F)
Unit 2 Unit
System Capacity (HP) 38 40
Model
Combination Unit
ARWN380LAS4 ARWN400LAS4
Independent Unit
ARWN200LAS4
ARWN180LAS4
ARWN200LAS4
ARWN200LAS4
Refrigerant Precharged Amount kg
3.0 + 3.0 3.0 + 3.0
Maximum Connectable Number of Indoor Units 61 64
Net Weight
kg
140 x 2 140 x 2
lbs
309 x 2 309 x 2
Dimensions(WxHxD)
mm
(755 × 997 × 500) x 2 (755 × 997 × 500) x 2
inch
(29-23/32 x 39-1/4 x 19-11/16) x 2 (29-23/32 x 39-1/4 x 19-11/16) x 2
Refrigerant
Connecting Pipes
Liquid mm(inch)
19.05(3/4) 19.05(3/4)
Gas mm(inch)
41.3(1-5/8) 41.3(1-5/8)
Water Connecting
Pipes
Inlet mm
PT 40 + PT 40 PT 40 + PT 40
Outlet mm
PT 40 + PT 40 PT 40 + PT 40
Drain Outlet mm
20 20
Temp. range of
Circulation water
Cooling
10°C ~ 45°C(50°F ~ 113°F) 10°C ~ 45°C(50°F ~ 113°F)
Heating
-5°C ~ 45°C(23°F ~ 113°F) -5°C ~ 45°C(23°F ~ 113°F)
Unit 3 Unit
System Capacity (HP) 42 44 46
Model
Combination Unit
ARWN420LAS4 ARWN440LAS4 ARWN460LAS4
Independent Unit
ARWN200LAS4
ARWN120LAS4
ARWN100LAS4
ARWN200LAS4
ARWN120LAS4
ARWN120LAS4
ARWN200LAS4
ARWN140LAS4
ARWN120LAS4
Refrigerant Precharged Amount kg
3.0 + 3.5 + 3.4 3.0 + 3.5 + 3.5 3.0 + 5.8 + 3.5
Maximum Connectable Number of Indoor Units 64 64 64
Net Weight
kg
(140 x 1) + (125 x 2) (140 x 1) + (125 x 2) (140 x 1) + (127 x 1) + (125 x 1)
lbs (309 x 1) + (276 x 2) (309 x 1) + (276 x 2) (309 x 1) + (280 x 1) + (276 x 1)
Dimensions(WxHxD)
mm
(755 × 997 × 500) x 3 (755 × 997 × 500) x 3 (755 × 997 × 500) x 3
inch
(29-23/32 x 39-1/4 x 19-11/16) x 3 (29-23/32 x 39-1/4 x 19-11/16) x 3 (29-23/32 x 39-1/4 x 19-11/16) x 3
Refrigerant
Connecting Pipes
Liquid mm(inch)
19.05(3/4) 19.05(3/4) 19.05(3/4)
Gas mm(inch)
41.3(1-5/8) 41.3(1-5/8) 41.3(1-5/8)
Water Connecting
Pipes
Inlet mm
PT 40 + PT 40 + PT 40 PT 40 + PT 40 + PT 40 PT 40 + PT 40 + PT 40
Outlet mm
PT 40 + PT 40 + PT 40 PT 40 + PT 40 + PT 40 PT 40 + PT 40 + PT 40
Drain Outlet mm
20 20 20
Temp. range of
Circulation water
Cooling
10°C ~ 45°C(50°F ~ 113°F) 10°C ~ 45°C(50°F ~ 113°F) 10°C ~ 45°C(50°F ~ 113°F)
Heating -5°C ~ 45°C(23°F ~ 113°F) -5°C ~ 45°C(23°F ~ 113°F) -5°C ~ 45°C(23°F ~ 113°F)
