(6) Remove WIFI-BT module, IR module
1) Remove screws to separate the IR Module Sub-
set.(Using the same Screw driver with “+” tip. As
before)
2) Separate IR module from IR Bracket by loosen
the snap t.
3) Remove the cable from the IR Module.
4) Remove screws to separate the WiFi Module
Subset.( Using the same Screw driver with “+” tip.
As before)
5) Remove the cable from the WiFi Module.
*Precaution : Separate Cable from WiFi Bracket by
loosen the snap t.
6) Disassemble complete as shown Picture.
