(8) DisAssemble and UnFix the SUB PCB ASSY from the MODULE.
(9) Disassemble SPEAKER L/R.
Release
1
2
Release
BRACKET ASSEMBLY,SUB
SCREW,MACHINE
BRH + 3MM 5.5MM SWCH18A FZMW N
BRACKET OLED48CX - IR ASSY(IR
No
Description Qty
①
②
1
1
Specification
IR ASSY
WIFI ASSY
RH
LH
1
2
SPEAKER ASSEMBLY
SPEAKER ASSEMBLY
K0600711 65 55 CX BX LEFT 20W
K0600712 65 55 CX BX RIGHT 20W
No
Description Qty
①
②
1
1
Specification
