LG OLED55B7P Service Manual

B. Power error
Off when on, off while viewing, power auto on/off
Error?
N
Y
Check Power Off
Mode
Fix A/C cord & Outlet
and check each 2
phase out
Check A/C cord
Check for all 2- phase
power out
Check outlet
Replace Main B/D
CPU
Abnormal
(If Power Off mode
is not displayed)
Check Power B/D
voltage
Y
N
Replace Main B/D
Normal
voltage?
Replace Power B/D
Replace Power B/D
N
Y
Normal?
End
※ Caution
Check and fix exterior
of Power B/D Part
☞A10
☞A9
Established
date
Revised date
7/15
Error
symptom
Standard Repair Process
7
Status Power off List Explanation
Normal
"POWER_OFF_BY_REMOTE_KEY” Power off by REMOTE CONTROL
"POWER_OFF_BY_OFF_TIMER" Power off by OFF TIMER
"POWER_OFF_BY_SLEEP_TIMER" Power off by SLEEP TIMER
"POWER_OFF_BY_INSTOP" Power off by INSTOP KEY
"POWER_OFF_BY_AUTO_OFF" Power off by AUTO OFF
"POWER_OFF_BY_ON_TIMER" Power off by ON TIMER
"POWER_OFF_BY_RS232C" Power off by RS232C
"POWER_OFF_BY_RESREC" Power off by Reservated Record
"POWER_OFF_BY_RECEND" Power off by End of Recording
"POWER_OFF_BY_SW_DW" Power off by S/W Download
"POWER_OFF_BY_UNKNOWN" Power off by unknown status except listed case
Abnormal
"POWEROFF_ABNORMAL1" Power off by abnormal status except CPU trouble
"POWEROFF_CPUABNORMAL" Power off by CPU Abnormal
* Please refer to the all cases which
can be displayed on power off mode.
Abnormal
1
