- 12 -
Copyright © LG Electronics Inc. All rights reserved.
Only training and service purposes.
+3.3V_NORMAL
SCL0
SDA0
2.4KΩ
IC101
Main SoC
+3.3V_NORMAL
3.3KΩ
33Ω
NVRAM
+3.3V_NORMAL
Audio Amp
Front
SCL2
SDA2
SCL4
SDA4
SCL5
SDA5
SCL1
SDA1
Micom
33Ω
3.3KΩ
+3.3V_NORMAL
100Ω
33pF
DC-DC
0.9V CORE
33Ω
100KΩ
Vx1 51p Wafer
33Ω
3.3KΩ
2.7KΩ
+3.3V_TU
LNB
33Ω
1.8KΩ
33Ω
Tuner
+3.3V_TU
SCL3
SDA3
47pF
2. I2C Map
