LG OLED55B8STB User Manual

- 17 -
Copyright © LG Electronics Inc. All rights reserved.
Only training and service purposes.
Main SoC
OCP
USB1(2.0)_V
+5V_USB_1
USB2.0_1_DM/DP0_JACK
USB2.0_1_DM/DP0
AA37[USB3_0_DP0]
AA36[USB3_0_DM0]
W37[GPIO91/EB_CS1] W36[GPIO90/EB_CS0]
/USB_OCD1
USB_CTL1
+5V_NORMAL
OCP
+5V_USB_2
USB2.0_2_DM/DP0_JACK
USB2.0_2_DM/DP1
AU31[USB2_1_DP0]
AT31[USB2_1_DM0]
/USB_OCD2
USB_CTL2
OCP
+5V_USB_3
USB2.0_3_DM/DP0_JACK
USB2.0_3_DM/DP0
AU30[UB2_0_DP0]
AT30[USB2_0_DM0]
AL24[JTMS1/SPI_CS1/GPIO33]
AL25[JTDO1/SPI_DO1/GPIO34]
/USB_OCD3
USB_CTL3
USB2(2.0)_H
USB3(2.0)_H
AM33[GPIO94] AM34[GPIO95]
+3.5V_WIFI
WIFI_DP/DM_JACK
WIFI_DP/DM
MICOM
BT_WAKEUP_HOST
BT_WAKEUP_DEVICE
COMBO_RESET
WOL/WIFI_POWER_ON
AT8[USB2_2_DP0]
AU8[USB2_2_DM0]
UART
SOC_RX/TX
AM12[UART0_RXD/GPIO106]
AL12[UART0_TXD/GPIO105]
SOC_TX/RX
7. USB / Wi-Fi / BT / UART
