- 7 -

Only training and service purposes.

5. External Input Support Format

5.1. CVBS input

5.2. Component input(Y, C

B/PB, CR/PR)

No. Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz) Proposed

1 720*480i 15.73 59.94 13.50 SDTV, DVD 480I(525I)

2 720*480i 15.75 60.00 13.51 SDTV, DVD 480I(525I)

3 720*576i 15.62 50.00 13.50 SDTV, DVD 576I(625I) 50Hz

4 720*480p 31.47 59.94 27.00 SDTV 480P

5 720*480p 31.50 60.00 27.03 SDTV 480P

6 720*576p 31.25 50.00 27.00 SDTV 576P 50Hz

7 1280*720 44.96 59.94 74.18 HDTV 720P

8 1280*720 45.00 60.00 74.25 HDTV 720P

9 1280*720 37.50 50.00 74.25 HDTV 720P 50Hz

10 1920*1080 28.12 50.00 74.25 HDTV 1080I 50Hz,

11 1920*1080 33.72 59.94 74.18 HDTV 1080I

12 1920*1080 33.75 60.00 74.25 HDTV 1080I

13 1920*1080 56.25 50.00 148.50 HDTV 1080P

14 1920*1080 67.43 59.94 148.50 HDTV 1080P

15 1920*1080 67.50 60.00 148.50 HDTV 1080P

No. Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz) Proposed Remarks

1 720*480i 15.73 59.94 13.50 SDTV, DVD 480I(525I) NTSC-M

2 720*480i 15.73 60.00 13.51 SDTV, DVD 480I(525I) NTSC-M

3 720*576i 15.63 50.00 13.50 SDTV, DVD 576I(625I) 50Hz PAL-BDGHI
