LG OLED55C1PUB User Manual

15
󱂃 Connections
You can connect various external devices to the TV. For more information on external device’s connection, refer to the manual provided with each
device.
HDMI
• When connecting the HDMI cable, the product and external devices should be turned off and unplugged.
• Supported HDMI Audio format (Depending upon model):
True HD (48 kHz),
Dolby Digital / Dolby Digital Plus (32 kHz, 44.1 kHz, 48 kHz),
PCM (32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz)
Note
If the device connected to Input Port also supports HDMI Deep Color, your picture may be clearer. However,
if the device doesn’t support it, it may not work properly. In that case, change the TV’s [HDMI Deep Color]
setting to off.
• → → [General] → [Devices] → [HDMI Settings] → [HDMI Deep Color]
(OLED48/55/65/77A1*)
- On: Support 4K @ 50/60 Hz (4:4:4, 4:2:2, 4:2:0),
- Off: Support 4K @ 50/60 Hz (4:2:0)
(OLED55/65/77B1*)
- On: Support 4K @ 50/60 Hz (4:4:4, 4:2:2, 4:2:0),
<3,4 port only> 4K @ 100/120 Hz (4:4:4, 4:2:2, 4:2:0)
- Off: Support 4K @ 50/60 Hz (4:2:0)
(OLED48/55/65/77/83C1*)
- On: Support 4K @ 50/60 Hz (4:4:4, 4:2:2, 4:2:0),
4K @ 100/120 Hz (4:4:4, 4:2:2, 4:2:0)
- Off: Support 4K @ 50/60 Hz (4:2:0)
• Use a certified cable with the HDMI logo attached. If you do not use a certified HDMI cable, the screen may
not display or a connection error may occur.
• Recommended HDMI cable types (3 m (9.84 ft) or less)
- Ultra High Speed HDMI
®
/™ cable
Note
• For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm (0.39 inches)
thick and 18 mm (0.7 inches) width.
• Use an extension cable that supports if the USB cable or USB flash drive does not fit into your TV’s USB
port.
A
B
A
B
* A ≦ 10 mm (0.39 inches)
* B ≦ 18 mm (0.7 inches)

LG OLED55C1PUB Specifications

General

Screen Type	oled
Color	black
Wall Mount	300mm x 200mm
Tuner	digital, atsc, clear qam
Screen Size	54.6 inches, 55 inches
Screen Technology	standard oled
Resolution	4k (2160p)
Refresh Rate	120hz
Closed Captioning	yes
HDR	yes
HDR Format	dolby vision, hdr 10, hybrid log-gamma (hlg)
Built-In Speakers	true, downward firing
Surround Sound	dolby atmos
Speakers Output	40 watts
HDMI Ports	4
HDMI 2.1 Ports	4
HDMI ARC Ports	yes
USB Ports	3
USB 2.0 Ports	3
USB 3.0 Ports	0
Ethernet	yes
RF Antenna	yes
Bluetooth	true, 5.0
Network	built-in wi-fi, ethernet
Headphones Output	yes
Digital Optical Audio Outputs	1
Analog Audio Outputs	0
Component Video Inputs	0
Composite Video Inputs	0
DVI	0
VGA Ports	0
SmartTV	webos
Streaming Services	hbo max, netflix, prime video, disney+, apple tv+, hulu, paramount+, peacock, youtube tv, spotify, iheartradio
Smart Applications	google assistant, amazon alexa, apple homekit
Other Devices Connection	mobile to tv
Voice Assistant	google assistant, amazon alexa
Remote Control	magic, voice control
3D	no
Power Consumption	196 kilowatt hours
Depth with Stand	9.9 inches
Height with Stand	29.1 inches
Width with Stand	48.3 inches
Net Weight with Stand	50.7 pounds
Depth without Stand	1.8 inches
Height without Stand	27.8 inches
Net Weight without Stand	41.7 pounds
