LG OLED55E6P User Manual

THERMAL
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
2015.06.02
C1405
10uF
10V
R1403
1.2K
1%
C1403
0.1uF
16V
OPT
+3.3V_NORMAL
C1401
0.1uF
50V
R1405
2.7K
1%
IC1400
BD86106EFJ
3
AGND
2
VIN
4
FB
1
PGND
5
COMP
6
EN
7
SW_1
8
SW_2
9
[EP]
R1402
10K
POWER_ON/OFF1
C1402
1500pF
50V
R1404
7.5K
1%
+13V
C1407
10uF
10V
C1400
10uF
25V
L1400
BLM18PG121SN1D
C1404
10uF
10V
C1406
10uF
10V
L1401
2.2uH
PS064T-2R2MS
R1401
10K
ZD1400
5V
R2
Vout=0.8*(1+R1/R2)
+3.3V_NORMAL
R1
6A
Copyright © 2016 LG Electronics Inc. All rights reserved.
Only for training and service purposes
LGE Internal Use Only

LG OLED55E6P Specifications

General

Screen Type	oled
Wall Mount	400mm x 200mm
Features	cinematic color, perfect black panel, ultra luminance
Tuner	digital
Screen Size	54.6 inches, 55 inches
Resolution	4k (2160p)
Refresh Rate	60hz
HDR	yes
HDR Format	dolby vision
Built-In Speakers	yes
Surround Sound	other
Speakers Output	40 watts
HDMI Ports	4
HDMI 2.1 Ports	0
HDMI ARC Ports	yes
USB Ports	3
Ethernet	yes
RF Antenna	yes
Network	built-in wi-fi, ethernet
Digital Optical Audio Outputs	1
Analog Audio Outputs	0
Component Video Inputs	0
Composite Video Inputs	1
DVI	0
SmartTV	webos
Streaming Services	netflix, youtube
Voice Assistant	other
Remote Control	universal
3D	yes
Power Consumption	198 kilowatt hours
Depth with Stand	6.9 inches
Height with Stand	30.2 inches
Width with Stand	48.8 inches
Net Weight with Stand	40.8 pounds
Depth without Stand	2.2 inches
Height without Stand	30.2 inches
Net Weight without Stand	37.7 pounds
