5. 2D Mode

5.1. Component input(Y, CB/PB, CR/PR)

No. Resolution H-freq.(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed

1 720*480i 15.73 59.94 13.500 SDTV, DVD 480I(525I)

2 720*480i 15.75 60.00 13.514 SDTV, DVD 480I(525I)

3 720*576i 15.625 50.00 13.500 SDTV, DVD 576I(625I) 50Hz

4 720*480p 31.47 59.94 27.000 SDTV 480P

5 720*480p 31.50 60.00 27.027 SDTV 480P

6 720*576p 31.25 50.00 27.000 SDTV 576P 50Hz

7 1280*720 44.96 59.94 74.176 HDTV 720P

8 1280*720 45.00 60.00 74.250 HDTV 720P

9 1280*720 37.50 50.00 74.250 HDTV 720P 50Hz

10 1920*1080 28.125 50.00 74.250 HDTV 1080I 50Hz,

11 1920*1080 33.72 59.94 74.176 HDTV 1080I

12 1920*1080 33.75 60.00 74.25 HDTV 1080I

13 1920*1080 56.25 50 148.5 HDTV 1080P

14 1920*1080 67.43 59.94 148.5 HDTV 1080P

15 1920*1080 67.50 60.00 148.5 HDTV 1080P

5.2. HDMI Input (PC)

No Resolution H-freq.(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remarks

1 640*350 31.468 70.09 25.17 EGA

2 720*400 31.469 70.08 28.32 DOS

3 640*480 31.469 59.94 25.17 VESA(VGA)

4 800*600 37.879 60.31 40 VESA(SVGA)

5 1024*768 48.363 60.00 65 VESA(XGA)

6 1360*768 47.712 60.015 84.75 VESA(WXGA)

7 1152*864 54.348 60.053 80 VESA

8 1280*1024 63.981 60.020 109.00 SXGA Support to HDMI-PC

9 1920*1080 67.5 60 158.40 WUXGA(Reduced

Blanking)

10 3840*2160 54 24.00 297.00 UDTV 2160P

11 3840*2160 56.25 25.00 297.00 UDTV 2160P

12 3840*2160 67.5 30.00 297.00 UDTV 2160P

13 4096*2160 53.95 23.97 296.703 UDTV 2160P

14 4096*2160 54 24 297 UDTV 2160P
