LG OLED55E6P User Manual

THERMAL
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
R5223 33
R5202
1M
OPT
+3.5V_WOL
EPHY_ACTIVITY
IC5200
RTL8201F-VB-CG
EAN62219201
1
RSET
3
MDI+[0]
7
AVDD33_1
9
RXD[0]
10
RXD[1]
11
RXD[2]/INTB
12
RXD[3]/CLK_CTL
13
RXC
14
DVDD33
15
TXC
16
TXD[0]
17
TXD[1]
18
TXD[2]
19
TXD[3]
20
TXEN
21
PHYRSTB
22
MDC
23
MDIO
24
LED0/PHYAD[0]/PMEB
25
LED1/PHYAD[1]
26
CRS/CRS_DV
27
COL
28
RXER/FXEN
29
DVDD10OUT
30
AVDD33_2
31
CKXTAL1
32
CKXTAL2
5
MDI+[1]
8
RXDV
6
MDI-[1]
4
MDI-[0]
2
AVDD10OUT
33
[EP]
C5203
0.1uF
16V
C5205
0.1uF
16V
WOL_CTL
EPHY_REFCLK
C52001
0.1uF
16V
OPT
LAN_JACK_POWER
+3.5V_ST
EPHY_RXD0
R5215
3.3K
X5200
EAW62583503
4
FLOAT_2
1
IN/OUT_1
2
FLOAT_1
3
IN/OUT_2
R5222
10K
OPT
R5217
3.3K
/RST_PHY
EPHY_RDN
C5208
0.1uF
16V
EPHY_TDN
EPHY_RDP
R5205
3.3K
C5202
5pF
EPHY_TXD1
WOL/ETH_POWER_ON
C5209
33pF
C5200
4.7uF
10V
C5206
5pF
50V
Ethernet_XTAL_LoadCap_Default
C5211
0.1uF
16V
R5212 1.5K
+3.5V_WOL
R5208
3.3K
ET_RXER
ET_RXER
R5204 2.49K
1%
R5209
51
ET_COL/SNI
ET_COL/SNI
+3.5V_WOL
EPHY_MDIO
EPHY_RXD1
R5219 10K
EPHY_MDC
EPHY_ACTIVITY
EPHY_TXD0
C5201
0.1uF
16V
R5200
3.3K
R5218
0
EPHY_TDP
+3.5V_WOL
R5203
3.3K
EPHY_CRS_DV
EPHY_EN
C5204
0.1uF
R5210
33
IC5201
AP2151AW
EAN64130101
3
FLG
2
GND
4
EN
1
OUT
5
IN
R5201 3.3K
C5206-*1
3.9pF
50V
Ethernet_XTAL_LoadCap_OLED_E6
C5207-*1
7pF
50V
Ethernet_XTAL_LoadCap_OLED_E6
C5207
5pF
50V
Ethernet_XTAL_LoadCap_Default
LAN
PAGE 52
2015.11.04
52
M16
100
Place near IC
ETHERNET INTERFACE
- CROSS CONNECTION
(PATTERN ISSUE)
Place this Res. near IC
WOL POWER ENABLE CONTROL
Place this cap. near IC
Place this cap. near IC
Place 0.1uF close to each power pins
Route Single 50 Ohm, Differential 100 Ohm
(from SOC)
Discharge Resistor
Copyright © 2016 LG Electronics Inc. All rights reserved.
Only for training and service purposes
LGE Internal Use Only

LG OLED55E6P Specifications

General

Screen Type	oled
Wall Mount	400mm x 200mm
Features	cinematic color, perfect black panel, ultra luminance
Tuner	digital
Screen Size	54.6 inches, 55 inches
Resolution	4k (2160p)
Refresh Rate	60hz
HDR	yes
HDR Format	dolby vision
Built-In Speakers	yes
Surround Sound	other
Speakers Output	40 watts
HDMI Ports	4
HDMI 2.1 Ports	0
HDMI ARC Ports	yes
USB Ports	3
Ethernet	yes
RF Antenna	yes
Network	built-in wi-fi, ethernet
Digital Optical Audio Outputs	1
Analog Audio Outputs	0
Component Video Inputs	0
Composite Video Inputs	1
DVI	0
SmartTV	webos
Streaming Services	netflix, youtube
Voice Assistant	other
Remote Control	universal
3D	yes
Power Consumption	198 kilowatt hours
Depth with Stand	6.9 inches
Height with Stand	30.2 inches
Width with Stand	48.8 inches
Net Weight with Stand	40.8 pounds
Depth without Stand	2.2 inches
Height without Stand	30.2 inches
Net Weight without Stand	37.7 pounds
