- 19 -
Copyright ©
LG Electronics. Inc. All rights reserved.
Only for training and service purposes.
FAB30016101 (M4*8mm, Black) 4EA
FAB30016103 (M4*12mm, Black) 4E
FAB32418704 (M3*5.5mm, Gray) 6EA
3. Disassemble Back Cover
4. Disassemble Speaker Box Assy
(1) Remove the screws (4EA)
(2) Grasp the left side of back cover and lift the back cover
(3) Separate the back cover
(1) Remove the screws (10EA)
(2) Separate the speaker box assy
To Next Page
