LG OLED55E7 series

- 20 -
Copyright ©
LG Electronics. Inc. All rights reserved.
Only for training and service purposes.
FAB31639801(M4*10mm, Black) 4EA
FAB31639801(M4*10mm, Black) 1EA
2.
1.
3.
5. Disassemble Stand Supporter Bracket
6. Disassemble IR Bracket & Separate the Cable
(1) Remove the screws (4EA)
(2) Separate the stand supporter bracket
(1) Separate the cable
(2) Remove the screw (1EA)
(3) Separate the IR bracket
