LNB Power
To enable the power supply for the LNB, select On. If you select Off, Motor Type is
disabled.
DiSEqC
When using DiSEqC, select one option from A~D/ToneA~B. If you use DiSEqC,
Unicable and Motor Type are disabled.
Unicable
Select On to use Unicable and set the Unicable in the Unicable Settings menu.
When Unicable is enabled, 22kHz Tone, DiSEqC, Motor Type are disabled.
Motor Type
Select Motor Type to use Motor and set the Motor in the Motor Setting menu. When
Motor is enabled, 22kHz Tone, DiSEqC, Unicable are disabled.
If you set satellite to others, you must add a transponder using Transponder Edit.
When selecting 22kHz Tone and DiSEqC, you must connect them in the same position as
displayed on the OSD.
If you delete a Satellite, all programmes stored in the Satellite are deleted.
Set Motor Setting
DiSEqC 1.2 : Control motor to change satellite dish position.
Drive Direction
Select the direction in which you want to move the motor.
Drive Mode
Two modes are available : Step and Continuous.
Test Transponder
Select the test Transponder you want to tune.
Set Limit
Step : The motor moves based on the value you enter (from 1 to 128).
●
Continuous : The motor moves continuously until you press the Stop.
●
