LG OLED65B6T Service Manual

- 7 -
LGE Internal Use Only
Copyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5. External input format
5.1. 2D Mode
5.1.1. Component input(Y, PB, PR)
5.1.2. HDMI Input (PC/DTV)
No
Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
1
720*480i 15.73 59.94 13.50 SDTV, DVD 480I(525I)
2
720*480i 15.75 60.00 13.51 SDTV, DVD 480I(525I)
3
720*576i 15.62 50.00 13.50 SDTV, DVD 576I(625I) 50Hz
4
720*480p 31.47 59.94 27.00 SDTV 480P
5
720*480p 31.50 60.00 27.02 SDTV 480P
6
720*576p 31.25 50.00 27.00 SDTV 576P 50Hz
7
1280*720 44.96 59.94 74.17 HDTV 720P
8
1280*720 45.00 60.00 74.25 HDTV 720P
9
1280*720 37.50 50.00 74.25 HDTV 720P 50Hz
10
1920*1080 28.12 50.00 74.25 HDTV 1080I 50Hz,
11
1920*1080 33.72 59.94 74.17 HDTV 1080I
12
1920*1080 33.75 60.00 74.25 HDTV 1080I
13
1920*1080 56.25 50 148.5 HDTV 1080P
14
1920*1080 67.43 59.94 148.5 HDTV 1080P
15
1920*1080 67.50 60.00 148.5 HDTV 1080P
No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed Remarks
HDMI-PC
1 640*350 31.46 70.09 25.17 EGA
2 720*400 31.46 70.08 28.32 DOS
3 640*480 31.46 59.94 25.17 VESA(VGA)
4 800*600 37.87 60.31 40 VESA(SVGA)
5 1024*768 48.36 60.00 65 VESA(XGA)
6 1360*768 47.71 60.01 84.75 VESA(WXGA)
7 1152*864 54.34 60.05 80 VESA
8 1280*1024 63.98 60.02 109.00 SXGA Support to HDMI-PC
9 1920*1080 67.5 60 158.40 WUXGA(Reduced Blanking)
10 3840*2160 54 24.00 297.00 UDTV 2160P
11 3840*2160 56.25 25.00 297.00 UDTV 2160P
12 3840*2160 67.5 30.00 297.00 UDTV 2160P
13 4096*2160 53.95 23.97 296.70 UDTV 2160P
14 4096*2160 54 24 297 UDTV 2160P
