Copyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
1. Application range
This spec sheet is applied to the LED TV used EA64B chassis
2. Test condition
Each part is tested as below without special notice.
(1) Temperature : 25 ºC ± 5 ºC(77±9ºF), CST : 40 ºC±5 ºC
(2) Relative Humidity: 65 % ± 10 %
(3) Power Voltage
Standard input voltage (100~240V@ 50/60Hz)
* Standard Voltage of each products is marked by models.
(4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
(5) The receiver must be operated for about 20 minutes prior
to the adjustment.
3. Test method
(1) Performance: LGE TV test method followed
(2) Demanded other specification
- Safety : UL, CSA, CE, IEC specification
- EMC : FCC, ICES, CE, IEC specification
No Item Specication Remark
1 Market North America
2 Broadcasting system Digital : DVB-T2, ATSC /64 & 256 QAM, ATSC
Analog : NTSC-M / NTSC-M
3 Available Channel VHF : 2 ~ 13
UHF : 14 ~ 69
DTV : 2 ~ 69
CATV : 1 ~ 135
CADTV : 1 ~ 135
DTV(UHD) : 2 ~ 69
4 Receiving system Digital : ATSC
Analog : NTSC-M
5 Video Input NTSC-M Rear RCA
6 Component Input Y/Cb/Cr, Y/ Pb/Pr Rear RCA
7 HDMI Input HDMI 1 PC / DTV format, Support HDCP2.2 Rear, Support 6Gbps
HDMI 2 PC / DTV format, Support HDCP2.2 Rear, Support 6Gbps, Support ARC
HDMI 3 PC / DTV format, Support HDCP2.2 Rear, , Support MHL 3.0 (external IC)
HDMI 4 PC / DTV format, Support HDCP2.2 Rear, Support 6Gbps(Only E6 / B6 model)
8 Audio Input Component / AV Audio / DVI audio L/R Input ; Rear
Component and av and DVI use same jack ;
Rear (Gender)
9 SPDIF out(1EA) Optical Audio out Rear (1EA),
10 USB Input(3EA) EMF, DivX HD, For SVC (download) JPEG, MP3, DivX HD
4. General Specification
4.1. Model Specification
