LG OLED65E6P Service Manual

- 11 -
LGE Internal Use Only
Copyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
No Resolution H-freq.(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remarks
1 1280*720 37.5 50 74.25 HDTV 720P 2D to 3D,
Side by Side(half), Top &
Bottom
2 1280*720 45.00 60.00 74.25 HDTV 720P
3 1280*720 44.96 59.94 74.176 HDTV 720P
4 1920*1080 33.75 60.00 74.25 HDTV 1080I
5 1920*1080 33.72 59.94 74.176 HDTV 1080I
6 1920*1080 28.12 50 74.25 HDTV 1080I
7 1920*1080 67.500 60 148.50 HDTV 1080P
8 1920*1080 67.432 59.94 148.352 HDTV 1080P
9 1920*1080 27.000 24.000 74.25 HDTV 1080P
10 1920*1080 28.12 25 74.25 HDTV 1080P
11 1920*1080 56.25 50 74.25 HDTV 1080P
12 1920*1080 26.97 23.976 74.176 HDTV 1080P
13 1920*1080 33.75 30.000 74.25 HDTV 1080P
14 1920*1080 33.71 29.97 74.176 HDTV 1080P
6.2.3. HDMI-PC Input (3D) (3D supported mode manually)
6.2.4. Component Input ( 3D) (3D supported mode manually)
No Resolution H-freq.(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remarks
1 1024*768 48.36 60 65 HDTV 768P 2D to 3D,
Side by Side(half), Top & Bottom
2 1920*1080 47.71 60 85.5 HDTV 1080P 2D to 3D,
Side by Side(half), Top & Bottom
3 3840*2160 67.500 60 148.50 HDTV 2160P 2D to 3D,
Side by Side(half), Top & Bottom
54 24.00 297.00
56.25 25.00 297.00
4 4096*2160 67.5 30.00 297.00 HDTV 2160P 2D to 3D,
Side by Side(half), Top & Bottom
5 4096*2160 54 24 297.00 2D to 3D,
Top & Bottom(half), Side by Side(half)
6 Others - - - 640*350
720*400
640*480
800*600
1152*864
2D to 3D,
Side by Side(half), Top & Bottom
