Page #10 background imageLoading...
Page #10 background image
- 10 -
Copyright © LG Electronics Inc. All rights reserved.
Only for training and service purposes.
BLOCK DIAGRAM
OCP
1.5A
Audio 3 AMP
Main IC
USB1 (2.0)
OPTIC
LAN
DDR4
(512MB X 2EA)
HDMI1 (2.1)
HDMI2 (2.1)
HDMI3 (2.1)
SYSTEM EEPROM
USB2 (2.0)
USB3 (2.0)
eMMC
Micom
P_TS
X_TAL
I2S Out
H/P
R
E
A
R
S
I
D
E
R
E
A
R
(H)
HP
AMP
SPDIF OUT
BLUTOOTH
IR/KEY/EYE
WIFI
SUB
ASSY
IR
KEY
I2C
CVBS/SIF
Tuner
(ARC)
X_TAL
OCP
1.5A
OCP
1.5A
HDMI4 (2.1)
DDR Controller
DDR4
(512MB X 2EA)
DDR4
(512MB X 2EA)
1. Main

Other manuals for LG OLED65E9PUA

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG OLED65E9PUA and is the answer not in the manual?

LG OLED65E9PUA Specifications

General IconGeneral
Screen Typeoled
Wall Mount300mm x 200mm
Features4k upscaling, perfect black, billion rich colours, pixel level dimming
Tunerdigital
Screen Size64.5 inches, 65 inches
Resolution4k (2160p)
Refresh Rate120hz
Closed Captioningyes
HDRyes
HDR Formatdolby vision, hdr 10, hybrid log-gamma (hlg)
Built-In Speakerstrue, front firing
Surround Sounddts-hd, dolby atmos
Speakers Output60 watts
HDMI ARC Portsyes
USB Ports3
USB 2.0 Ports3
Ethernetyes
RF Antennayes
Bluetoothtrue, 5.0
Networkbuilt-in wi-fi, ethernet
Headphones Outputyes
Digital Optical Audio Outputs1
Component Video Inputs0
Composite Video Inputs1
DVI0
SmartTVwebos
Smart Applicationsamazon alexa, apple homekit, google assistant
Voice Assistantamazon alexa, google assistant
Remote Controlmagic
3Dno
Power Consumption256 kilowatt hours
Depth with Stand8.7 inches
Height with Stand34.5 inches
Width with Stand57.1 inches
Net Weight with Stand75 pounds
Depth without Stand2 inches
Height without Stand34.5 inches
Net Weight without Stand44.1 pounds
