(16-1) ~ (16-3) Pull and raise up the Main PCB using both hands like below pictures.
Be care the tuner not to damage it.
When you separate the PCB, you need a little power because gap pads were stuck at the bottom of PCB.
※ you need a little power because
gap pads were stuck at the bottom of PCB.
16-1
16-2
16-3
OLED65G6 Disassembly Guide
