- 15 -
Copyright © LG Electronics Inc. All rights reserved.
Only training and service purposes.
200
LV1
LV2
HP1
800
400
540
544
120
530
200T
121
500
501
700
810
570
HW1
HS1
AR2
A10
A9
910
900
920
HT1
HT2
Stand base
+ Stand body
EXPLODED VIEW
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These
parts are identified by in the EXPLODED VIEW.
It is essential that these special safety parts should be replaced with the same components as
recommended in this manual to prevent Shock, Fire, or other Hazards.
Do not modify the original design without permission of manufacturer.
IMPORTANT SAFETY NOTICE
To Next Page
