USB FUNCTION
Check USB_5 V.
Display “NO USB”.
YES
YES
Check USB
D+/D-
YES
Plug-in usb device.
Check CN421.
NONO
YES
Display “READ”.
YES
Display “NO FILE”.
YES
Check USB jack
(CN461/ CN462).
NO
Replace IC501.
NO
Check IC501
(Pin U7, U8, A7, A8).
Check usb audio fi le in usb device
(MP3, WMA fi le is playable)
YES
4. DOUBLE USB FUNCTION
3-16
ELECTRICAL TROUBLESHOOTIHG GUIDE
