Appendix42
Appendix
6
Specifications
General
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D) Approx. 300.0 mm x 390.0 mm x 324.0 mm
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 60 % RH
Inputs/ Outputs
Analog audio in (AUX IN) 600 mV, 600
Ω
, RCA jack (L, R) x 1
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector ) x 1
Microphone (MIC 1/2) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 2
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency response 60 to 20,000 Hz
Signal-to-noise ratio More than 70 dB
Dynamic range More than 70 dB
Bus Power Supply (USB) 5 V
0
500 mA
y
Design and specications are subject to change without notice.
