Wired remote controller
Category Level1 Level2 (Code) Level3 (Code) DESCRIPTION
External
equipment
control
Mode setting On/Off/Auto
-
You can control external devices such as lights, fans, and heaters by using the signals
emitted by the remote controller.
- Output specification : DC 11~12 V , Max 30 mA
On : When it is set to “On”, it always performs the contact point output
Off : When you set it to “Off”, it does not perform the contact point output in any case.
Auto : If it is set to "Auto", a contact signal comes out according to the condition set in the
on/off condition of the user setting.
User setting
External device use Not use / Use
-
External device type
Motor/Lighting/
Fan/Heater/
Pump/Others
-
On condition
-
The external device is turned on by the set mode or temperature condition.
Off condition
-
The external device is turned off by the set mode or temperature condition.
Wi-Fi Wi-Fi pairing
- -
Enables the AP mode function of the Wi-Fi module connected to the indoor unit.
Zone /
Damper Control
Zone Control
(damper control)
- -
You can monitor or set the status of zone.
Function setting Zone Name
-
If the zone control of the indoor unit is "New type", You can set the zone name.
- Zone(default)/Office/Hallway/Lobby/Room/Living/Kitchen/Etc.
Installer setting
Static pressure
code : 06
V-H (06:01)
F-H (06:02)
V-L (06:03)
F-L (06:04)
This function can be set only in the duct products.
When using zone control, this is a function to change the fan air volume according to the
number of damper opening and closing and the static pressure of the indoor fan.
V-H : Variable - High static pressure
F-H : Fixed - High static pressure
V-L : Variable - Low static pressure
F-L : Fixed - Low static pressure
Zone Type
code : 13
Old (default)
(13:00)
New (4 zone)
(13:01)
This function sets the Zone type supported by indoor units such as "New" and "Old" type.
1) Old (default) - Only the condition of damper can be monitored.
2) New (4 zone) - 4 zone damper controller is installed. Both damper control and monitoring
are possible.
New (8 zone)
(13:02)
3) New (8 zone) - 8 zone damper controller is installed.
Both damper control and monitoring are possible.
Zone number
code : 14
2~4 for New 4 zone
(14:02~14:04)
If zone control of indoor unit is "New type", set the number of installed zone damper.
2~8 for New 8 zone
Static pressure step
Step 0 :
Not use (32:00)
Step 1~11
(32:01~32:11)
Static pressure step setting can be set only for duct products.
This function can set the static pressure of the product in 11 steps.
If Static pressure step setting(code:32) is used, the Static pressure(code:06) can not be
used.
2 set
control
Mode setting
Auto (dual set point)
-
The cooling and heating are automatically switched and operated through the desired tem-
perature setting for heating and cooling.
Override
-
It is a function to switch temporarily the status of the occupied/unoccupied of the set sched-
ule. (occupied ↔ unoccupied)
Home Leave(Setback)
-
When using the home leave mode(setback), the room temperature can be maintained at
the temperature set by the user.
Set the desired temperature in "Function Settings-Home leave set temperature".
The home leave mode is canceled when this mode is released directly or when the occu-
pied schedule starts.
Hold
-
This function maintains the current operation status without executing schedule.
It can be released only by releasing the hold function.
Temporary
-
It is a function that operates differently from the scheduled schedule by user's arbitrary
operation or external setting.
When the schedule event time is reached, the schedule operation is performed and the
temporary mode is released.
Function setting
Dead band setting 0 ~10℉(0~5℃)
It is the function to set the difference value of minimum interval between cooling desired
temperature and desired heating temperature.
Override set time 30~240 minutes
In case of occupied/unoccupied switching, the product operation is maintained in the
changed mode for the set time.
Home leave set temperature Cool/Heat Set the desired cooling and heating temperature when the home leave mode is executed.
Installer setting
Expand of temperature range
code : 31
Clear (31:00)
Set (31:01)
This function using in dual set point control mode.
This function is used to expand of temperature range.
Clear: 60~86°F (16~30°C) (Default)
Set : 40~99°F (4~37.5°C)
Guard timer
code : 33
0 minute (33:00)
15 minutes (33:01)
30 minutes (33:02)
45 minutes (33:03)
60 minutes (33:04)
This is the function to set the minimum waiting time for cooling / heating switching during
dual set mode operation.
It protects the outdoor unit by setting the waiting time when changing the outdoor unit cycle.
To Next Page
