5. SCHEMATIC DIAGRAM
5.1 CIRCUIT DIAGRAM
- 24 -
Copyright ©2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
R-8000A/WR-8020/R-8000AY3
PART NO.
2H00677P
2H00598E
4681A20027B/4681A20073A
6120AR2359V
2H01109L
6750A30001A/N
5416A20013B/5416A20014B
POWER CORD
ROTARY SWITCH
FAN MOTOR
CAPACITOR
THERMOSTAT
OVERLOAD PROTECTOR
COMPRESSOR
1
2
3
4
5
6
7
1
1
1
1
1
1
1
S
S
S
S
S
S
S
LOCATION
NO.
DESCRIPTION
RE-
MARKS
Q'TY
PER SET
1
3
6
4
2
7
5
MOTOR
COMP.
P.T.C
BR(YL)
S: Service Parts
N: Non Service Parts
