DISASSEMBLE INSTRUCTIONS
11
8-1. Disassemble the spring holder.
8-2. Releasing the belt on the pulley.
9-1. Disassemble the main PWB cover as
pulling the hook.
9-2. Pull out the harness from the housing.
⑤
7-1. Disassemle the door by releasing the
2 screws.
7-2. Disassemble the door switch.
7-3. Disassemble the cabinet cover by
releasing the 10 screws.
7-4. Disassemble the Door Switch.
7-5. Disassemble the cover, cabinet.
CABINET COVER
DOOR
Pull
DOOR SWITCH
Pull
1
Pull the Hook
Push
1
2
2
39
To Next Page
