DISASSEMBLE INSTRUCTIONS
11
Note
If the hose is assembled unsuitable
“empty water” error message will be
indicated on the LED or LCD display.
11. Disassemble the housing of motor,
compressor, heater and thermistor.
12. Releasing the dispenser by unscrewing
1 screw.
10. Disassembling the side frame by releasing
4 screws
DISPENSER
Heater thermistor (WH Small 2pin)
Heater housing (WH Big 2pin)
Motor housing (WH 3pin)
Compressor housing (BLUE 3pin)
40
To Next Page
