15
INSTALLATION
ENGLISH
Installing the Optional Drain
Hose
Normally, condensed water is pumped up to the
water container where water is collected until
manually emptied. Water can also be drained out
directly to a mains drain, especially when the
appliance is stacked on top of a washing machine.
With the connecting elbow or T piece of the mains
drain hose, simply change the water path and re-
route to the drainage facility as below:
1
Separate the anti-backflow lid
a
and the water
container hose
b
from the connecting elbow
or T piece.
2
Attach the anti-backflow lid
a
to the head of
the connecting elbow or T piece and then
connect the optional drain hose
c
to the
opposite side of the connecting elbow or T
piece.
• If the optional drain hose is installed in a way
that leaves it bent or pinched, drainage may not
function properly.
a
c
