LG RM-15LA70 User Manual

SPEAKER SPEAKER
SIDE AV
LOCAL KEY
IR_LED
(17LZ50 ONLY)
4P_2.0MM H-B
11P_2.0MM H-H 100MM
2P_AC_SOCKET
18P_1.0MM FFC 54MM
18P_1.0MM FFC 54MM (RZ ONLY)
(17LZ50 ONLY)
6P_2.0MM H-B
600MM
3P_2.5MM H-B
220MM
1. 20P LVDS : 200MM 2. 41P TTL 3. 50P TTL : 145MM
4P_2.5MM SHIELD RECEPTERCLE GND: 2PIN, 4PIN 500MM 750MM
1
4
5
3
2
6
8
9
7
WIRING DIAGRAM
No. Part No.
1 2 3 4 5 6 7 8
Wiring Part List
6631T25019Y 6631T11012R 6631T20028G 6631T20033U 6631T25021A 6631T11017N 6631T11017N

LG RM-15LA70 Specifications

General

Screen Size	15 inches
Display Type	LCD
Resolution	1024 x 768
Aspect Ratio	4:3
Contrast Ratio	500:1
Inputs	VGA, Composite, S-Video
Viewing Angle	160° (H) / 140° (V)
