Rear panel
a
Display window
b
1
(Standby)
Turns the power on or off.
F (Function)
Selects the function and input source.
C/V (Skip/Search)
- Skips backward or forward.
- You can search a folder by pressing and holding.
N (Play/Pause)
Starts or pauses playback.
REPEAT
Listens to your files repeatedly.
c
MASTER VOLUME
Adjusts speaker volume.
d
BASS
Adjusts BASS sound level when setting USER EQ.
e
TREBLE
Adjusts TREBLE sound level when setting USER EQ.
f
MIC (Microphone) ECHO
Adjusts echo volume.
g
MIC (Microphone) VOLUME
Adjusts microphone volume.
h
SD CARD slot
You can play sound files by connecting the SD card.
i
USB Port
You can play sound by connecting the USB device.
j
MIC (Microphone) 1/2 Jack
k
AC IN socket
l
LINE IN / OUT (L/R)
Connect an auxiliary device.
Carrying the unit
This unit have wheels and handle for carrying. You can
easily carry the unit.
a
b
c d e f g
h
i
j
k
l
Additional Information
Specifications
Power Requirements
Refer to the main label on
the unit.
Power Consumption
Refer to the main label on
the unit.
Dimensions (W x H x D)
Approx. 430 mm X
655 mm X 385 mm
Bus Power Supply (USB)
5 V 0 500 mA
Amplier
(Total RMS output power)
80 W RMS
Design and specications are subject to change without
notice.
LED Display table
LED displays and descriptions are as belows.
LED Display Description
HELLO
BYE
USB
SD
LINE
BT
READ
ONE
ALL
NO FILE
CONNECTED
NOT SUPPORT
RM2-NK.AZAFLLK_SIM_ENG_MFL71437210.indd 3-4 2020-03-11 9:21:19
